ერთიანი ჩამრთველი (სენსორული) LightCore (2-gang)

Description

Radio frequency bands
866.0–866.5 MHz
868.0–868.6 MHz
868.7–869.2 MHz
905.0–926.5 MHz
915.85–926.5 MHz
921.0–922.0 MHz
Depends on the sales region.
Maximum effective radiated power (ERP)
up to 20 mW
Radio signal modulation
GFSK
Radio communication range
up to 1,100 m
Between the device and a hub (or range extender) in an open space.

Encrypted radio communication
All the data stored and transmitted are protected by block encryption featuring a dynamic key.
Radio frequency hopping
Radio communication uses frequency hopping to prevent interception and jamming.

Key features
Automation scenarios
security mode change reactionsscheduled actionsalarm reactionstemperature scenarioshumidity scenarios²CO₂ concentration scenarios²by pressing another LightSwitch/Button

2 — Scenarios by humidity and CO₂ concentrations are available when LifeQuality Jeweller is added to the system.
Operation without a neutral wire
LightSwitch only needs a live wire to operate.
Power of switched device
from 5 to 300 W per segment
Contactless touch-sensitive panel
LightSwitch is activated when a hand gets as close as 15 mm from the panel.
Night backlight
Optional, can be turned off in the Ajax app device settings.
Protection against incompatible devices
Triggers if lighting devices have insufficient power (up to 5 W). If protection is triggered, LightSwitch turns off the power and sends a notification to Ajax apps. For low-power lighting devices, the kit includes a capacitor.
Recommendations
The device is designed for indoor use only. A professional electrician should install the device.
Sabotage protection
Protection against spoofing
device authentication
Communication loss detection
after 36 s
Detection time depends on the Jeweller or Jeweller/Fibra settings.

Power supply
Power supply voltage
230 V~, 50/60 Hz
The device does not need a neutral wire to operate.
Average consumption
up to 200 mW
Maximum power
300 W per segment (600 W in total)
For LightCore (2-gang) Jeweller and LightCore (2-gang) vertical Jeweller.
Current protection
more than 2.6 A
If protection is triggered, LightSwitch turns off the power and sends a notification to Ajax apps.
Temperature protection
more than +60 °C
If protection is triggered, LightSwitch turns off the power and sends a notification to Ajax apps.
Operating parameters
Operating temperature range
from –10 °C to +40 °C
Operating humidity
up to 75% with no condensation
Protection class
IP20
Form factor of the switch
European type (55)
